Paper Title:
Materials Design and Analysis of Low-Power MEMS Microspeaker Using Magnetic Actuation Technology
  Abstract

This paper presents material properties of a micromachined mesoscopic acoustic speaker for hearing aid applications. The microspeaker has a single turn copper coil on a polyimide membrane, and an NdFeB permanent magnet beneath the membrane. The fields due to the permanent magnet were computed using FEMM. Then, forces based on the fields and on the coil driving current were computed. Finally, IntelliSuite was employed to simulate membrane displacements and stresses. The device, with a polyimide membrane diameter of 2.5 mm and thickness of 2 µm, consumes 3.4 mW to generate a sound pressure level of 108 dB in the human ear.

  Info
Periodical
Edited by
Selin Teo, A. Q. Liu, H. Li and B. Tarik
Pages
243-246
DOI
10.4028/www.scientific.net/AMR.74.243
Citation
F. L. Ayatollahi, B. Y. Majlis, "Materials Design and Analysis of Low-Power MEMS Microspeaker Using Magnetic Actuation Technology", Advanced Materials Research, Vol. 74, pp. 243-246, 2009
Online since
June 2009
