Paper Title:
Development of Liquid Tunable Diffractive/Refractive Hybrid Lens Based on Combination of Diamond Turning and Soft Lithography
  Abstract

A liquid tunable diffractive/refractive hybrid lens which combines the use of high precision diamond turning and soft lithography is developed in this work. This diffractive/refractive hybrid lens comprises a Fresnel lens and a tunable refractive lens automatically aligned during the fabrication process. Multiple PDMS hybrid lens devices can be fabricated from the diamond-turned master mould and AFM results show that the surface quality of the PDMS lenses meets the requirements for optical purposes. The hybrid lens is tested with a green laser (λ = 532nm) and experimental results demonstrate a tunability of more than 20mm.

  Info
Periodical
Edited by
Selin Teo, A. Q. Liu, H. Li and B. Tarik
Pages
85-88
DOI
10.4028/www.scientific.net/AMR.74.85
Citation
H. M. Leung, H. B. Yu, G. Y. Zhou, A. Senthil Kumar, F. S. Chau, "Development of Liquid Tunable Diffractive/Refractive Hybrid Lens Based on Combination of Diamond Turning and Soft Lithography", Advanced Materials Research, Vol. 74, pp. 85-88, 2009
Online since
June 2009
Export
Price
$32.00
