Paper Title:
An Effect of Viscosity of Coating Materials on Silicon Micro-Patterning Arrays for Superhydrophobic Surface
  Abstract

Two different viscous coating materials, which are Polydimethylsiloxane (PDMS) mixed with 10%wt of Dicumylperoxide (DCP), and Semifluorinate Silane (SFS), were applied to silicon micro-asperity. The cosine’s Young and viscosity of those coating materials are -0.3584,-0.3496 and 3.176x10-3, 1.339 x10-3 Pas, respectively. The rough surfaces with nine asperity shapes were studied. The results shown that, pillar shape has an effect on water contact angle (WCA): Stripe asperity cannot make the average WCA greater than 150. When consider the pillar asperity, the WCA falls between 152 and 157, which exhibits a superhydrophobic surface property. However, actual WCA of the micro-asperity coated with PDMS+10%wt of DCP is lower than that coated with SFS around 1 to 7. High viscous material makes the asperity size bigger than the design and decreases the WCA: the low viscous material is more suitable for coating on the asperities.

  Info
Periodical
Advanced Materials Research (Volumes 93-94)
Edited by
S. Suttiruengwong and W. Sricharussin
Pages
447-450
DOI
10.4028/www.scientific.net/AMR.93-94.447
Citation
N. Atthi, O. Nimittrakoolchai, S. Supothina, J. Supadech, W. Jeamsaksiri, A. Pankiew, C. Hruanun, A. Poyai, "An Effect of Viscosity of Coating Materials on Silicon Micro-Patterning Arrays for Superhydrophobic Surface", Advanced Materials Research, Vols. 93-94, pp. 447-450, 2010
Online since
January 2010
