Paper Title:
Partial Matching Algorithm of 3D CAD Models Based on the Constraints of Transition Features
  Abstract

The CAD models of mechanical parts usually have many blends and chamfers, and the existence of these machining features can greatly change the geometric and topological patterns of the CAD models, but the existing partial matching algorithms cannot match the CAD models which contain machining features such as blends and chamfers. In this paper, a new approach to partial matching based on the constraints of transition features is proposed. Firstly, the transition features are identified by feature recognition, and then these machining features are removed to eliminate the impacts to the geometric and topological information of the CAD models, and the attribute adjacent graph is reconstructed, finally, the sub-graph isomorphism approach is used to achieve the partial matching. Experimental results show that this method can achieve partial matching of CAD models which contain machining features such as blends and chamfers, and the matching efficiency can satisfy the requirement of the engineering retrieval.

  Info
Periodical
Advanced Materials Research (Volumes 97-101)
Edited by
Zhengyi Jiang and Chunliang Zhang
Pages
3371-3375
DOI
10.4028/www.scientific.net/AMR.97-101.3371
Citation
K. X. Zhang, S. S. Zhang, X. L. Bai, "Partial Matching Algorithm of 3D CAD Models Based on the Constraints of Transition Features", Advanced Materials Research, Vols. 97-101, pp. 3371-3375, 2010
Online since
March 2010
