Paper Title:
Study on the Microstructure of Micro Laser Welded Joint of TiNi Shape Memory Alloy Sheet
  Abstract

Butt welding of 0.2mm thick TiNi shape memory alloy sheet was successfully realized by using micro impulse laser whose average power is 80W and the microstructure of welded joint was study in this paper. The results show that, the welded joint of micro laser welding can be divided into four zones according to grain size and microstructure. The microstructure in base metal zone is rolled structure and the grains are coarse and heterogeneous. The microstructures of welded seam center zone are fine equiaxed crystals and the microstructures of both lower surface and upper surface edge zone are columnar crystals. There is almost no obvious coarse grain heat-affected zone at the edge between welded seam and base metal. There is obvious segregation layer in local area of welded seam because the content of Ti and Ni elements is changed and different with base metal during the crystallizing course of welding pool.

  Info
Periodical
Advanced Materials Research (Volumes 97-101)
Edited by
Zhengyi Jiang and Chunliang Zhang
Pages
3936-3939
DOI
10.4028/www.scientific.net/AMR.97-101.3936
Citation
Y. H. Chen, L. M. Ke, Y. Liu, S. L. Xu, "Study on the Microstructure of Micro Laser Welded Joint of TiNi Shape Memory Alloy Sheet", Advanced Materials Research, Vols. 97-101, pp. 3936-3939, 2010
Online since
March 2010
Export
Price
$32.00
