Paper Title:
CAD/CAE System for Shaping Process of Three Dimensional Complicated Surfaces in Electrochemical Machining
  Abstract

The paper presented a computer aided design and engineering (CAD/CAE) system that can be used to simulate and analyse three-dimensional complicated workpiece’s shaping process in electrochemical mahining. In the CAE model the finite element method was applied to analysis the electric-field distribution in inter-electrode gap. Factors affecting the electric-field distribution, such as flow factors and passivating electrolyte, are also taken into account by using database technology. The results of simulation and experiments showed that the system was of high precision.

  Info
Periodical
Advanced Materials Research (Volumes 97-101)
Edited by
Zhengyi Jiang and Chunliang Zhang
Pages
4061-4065
DOI
10.4028/www.scientific.net/AMR.97-101.4061
Citation
L. Wang, "CAD/CAE System for Shaping Process of Three Dimensional Complicated Surfaces in Electrochemical Machining", Advanced Materials Research, Vols. 97-101, pp. 4061-4065, 2010
Online since
March 2010
