Paper Title:
Electrochemical Machining of the Turbulated Hole
  Abstract

Electrochemical machining (ECM) technology has the advantage of machining the workpiece with complex profile on the basis of electrolysis. In this study, turbulated holes with the rib’s shape of spiral and annular were processed by ECM by using the shaped cathodes. Experimental system was built which consists of electrolyte supply module, power supply unit and workpiece holding device. Machining experimentations were carried out on the built system. Analysis and discussions were done according to the experimental results. It indicated machining efficiency is high by using the shaped cathode. Machining error could be controlled within 10-20%.

  Info
Periodical
Advanced Materials Research (Volumes 97-101)
Edited by
Zhengyi Jiang and Chunliang Zhang
Pages
4088-4091
DOI
10.4028/www.scientific.net/AMR.97-101.4088
Citation
M. H. Wang, C.Y. Yao, Q. F. Zhang, W. Peng, "Electrochemical Machining of the Turbulated Hole", Advanced Materials Research, Vols. 97-101, pp. 4088-4091, 2010
Online since
March 2010
