Paper Title:
One-Point Nano-Grinding for Micro-Aspherical Glass Lens Mould
  Abstract

This paper reported an experimental study on ultra-precision grinding for micro aspherical lens mould. One-point grinding mode and inclined axis grinding mode are employed and investigated in grinding process. Grinding test of a micro-lens mould using form error compensation technique is conducted. The experimental results show that ground micro aspheric mould surfaces with form (PV) around 0.122 µm and a roughness (Ra) less than 2 nm is achieved successfully.

  Info
Periodical
Advanced Materials Research (Volumes 97-101)
Edited by
Zhengyi Jiang and Chunliang Zhang
Pages
4217-4220
DOI
10.4028/www.scientific.net/AMR.97-101.4217
Citation
S. H. Yin, Y. Wang, Y. F. Fan, Y. J. Zhu, F. J. Chen, T. Hu, J. B. He, "One-Point Nano-Grinding for Micro-Aspherical Glass Lens Mould ", Advanced Materials Research, Vols. 97-101, pp. 4217-4220, 2010
Online since
March 2010
