Paper Title:
An Improved Calibration Method for Optical 3D Measuring System Using Cross Target Based on Bundle Adjustment Algorithm
  Abstract

This paper presents an accurate calibration method of binocular 3D measurement systems for industrial on-site inspection, which uses a cross target with ring coded points. The cross target can be used to calibrate large-scale field-of-view stereo measurement systems and obtain higher measurement precision conveniently. The world coordinates of these ring coded points are not required. The calibration initial value is computed by using the relative orientation method and the Direct Linear Transform (DLT) method of photogrammetry. The bundle adjustment algorithm is used to optimize the calibration parameters as well as the 3D coordinates of the ring coded points. Experiment results show that the RMS error of the reprojection in our method is less than 0.05 pixels and the measurement error is 0.011 mm compared with the Coordinate Measuring Machine (CMM).

  Info
Periodical
Advanced Materials Research (Volumes 97-101)
Edited by
Zhengyi Jiang and Chunliang Zhang
Pages
4237-4242
DOI
10.4028/www.scientific.net/AMR.97-101.4237
Citation
Z. Z. Xiao, J. Liang, D. H. Yu, Z. Z. Tang, " An Improved Calibration Method for Optical 3D Measuring System Using Cross Target Based on Bundle Adjustment Algorithm ", Advanced Materials Research, Vols. 97-101, pp. 4237-4242, 2010
Online since
March 2010
Export
Price
$32.00
