Paper Title:
A Circle Contour Measurement Technique Based on Randomized Hough Transform Using Gradient Information
  Abstract

Hough Transform (HT) is an image edge detection technique which is widely used in pattern recognition and computer vision. In this paper the fundamental principle of HT is analyzed and the defect of HT and Randomized Hough Transform (RHT) is indicated. An algorithm based on RHT and the information of grayscale and gradient in image is proposed. It uses the property of the pattern and is mainly used for detection of circle and arc contour measurement. This algorithm can decrease memory usage in computer by a multi to one mapping, accelerate the calculation speed by parallel algorithm, improve the edge detection accuracy by subpixel division, obtain the parameters of object by applying least square fitting algorithm. Based on the principle, a measurement system with high accuracy and efficiency in image capturing and processing is developed. Experiments are carried out in the system. The result of experiment has certified the feasibility and validity of the algorithm.

  Info
Periodical
Key Engineering Materials (Volumes 295-296)
Edited by
Yongsheng Gao, Shuetfung Tse and Wei Gao
Pages
277-282
DOI
10.4028/www.scientific.net/KEM.295-296.277
Citation
J. W. Cui, J. B. Tan, "A Circle Contour Measurement Technique Based on Randomized Hough Transform Using Gradient Information", Key Engineering Materials, Vols. 295-296, pp. 277-282, 2005
Online since
October 2005
