Paper Title:
Design, CFD Investigation and Implementation of a Novel Diverter Mechanism for Water Flow Measurement
  Abstract

Fluid flow diverter serves as an essential element in high accuracy liquid flow calibration facility using a static weighing gravimetric system coupled with a flying-start-and-finish mechanism. For such flow system, stability and patterns of flow that passing through the draining nozzle and diverting module influence the accuracy of flow rate measurement. Consequently, the design and implementation of a diverter mechanism with feeding pipe section contribute dearly to the total measurement uncertainty of a standard calibration facility. In this research, a draining nozzle that changes from circular cross section to rectangular was specially developed to provide fluent flow transition. To facilitate the design process, the computational fluid dynamics (CFD) was introduced that effectively reduced the time consumption for prototype construction and test. The selected design exhibited symmetric and stable flow patterns in the desired operational flow range.

  Info
Periodical
Key Engineering Materials (Volumes 295-296)
Edited by
Yongsheng Gao, Shuetfung Tse and Wei Gao
Pages
521-526
DOI
10.4028/www.scientific.net/KEM.295-296.521
Citation
Y.L. Ho, J. Y. Chen, J. H. Shaw, C.T. Yang, "Design, CFD Investigation and Implementation of a Novel Diverter Mechanism for Water Flow Measurement", Key Engineering Materials, Vols. 295-296, pp. 521-526, 2005
Online since
October 2005
Export
Price
$32.00
Share
