Paper Title:
The Research on New Grinding Head Used for Tool's Radius Offset of Spatial Conical Enveloping Surface Grinding
  Abstract

A basic method and characteristic of tool’s radial offset for conical enveloping surface, its structure and working theory as well as the most advanced planetary grinding head used in tool’s radial offset in the world are introduced. In order to improve the dynamic property of grinding head and method used in tool’s offset in existence, a new type of grinding head that can realize tool’s radial offset to big tool’s radial error was developed. It has the advantages of simpler structure, easier machining, lower cost, continuous and stable machining, and high efficiency, and is a new method of complex tool’s position offset.

  Info
Periodical
Key Engineering Materials (Volumes 304-305)
Edited by
Guangqi Cai, Xipeng Xu and Renke Kang
Pages
512-515
DOI
10.4028/www.scientific.net/KEM.304-305.512
Citation
Y. T. Zhang, Z. Q. Hu, K. J. Kang, Y.K. Li, "The Research on New Grinding Head Used for Tool's Radius Offset of Spatial Conical Enveloping Surface Grinding ", Key Engineering Materials, Vols. 304-305, pp. 512-515, 2006
Online since
February 2006
Export
Price
$32.00
Share
