Paper Title:
Material Removal Model and Experimental Verification for Abrasive Jet Precision Finishing with Wheel as Restraint
  Abstract

The material removal rate (MRR) model was investigated in abrasive jet precision finishing (AJPF) with wheel as restraint. When abrasive wore and workpiece surface micro-protrusion removed, the size ratio for characteristic particle size to minimum film thickness gradually diminishing, the abrasive machining from two-body lapping to three-body polishing transition in AJPF with grinding wheel as restraint. In the study, the material removal rate model was established according to machining mechanisms and machining modes from two-body to three-body process transition condition, and active number of particles in grinding zone were calculated and simulated. Experiments were performed in the plane grinder for material removal mechanism and academic models verification. It can be observed from experimental results that the surface morphology change dramatically to a grooved or micro-machined surface with all the grooves aligned in the sliding direction in two-body lapping mode. On the other hand, the surface is very different, consists of a random machining pits with very little sign of any directionality to the deformation in the three-body machining mode. Furthermore, the material removal rate model was found to give a good description of the experimental results.

  Info
Periodical
Key Engineering Materials (Volumes 304-305)
Edited by
Guangqi Cai, Xipeng Xu and Renke Kang
Pages
555-559
DOI
10.4028/www.scientific.net/KEM.304-305.555
Citation
C. H. Li, G. Q. Cai, S. C. Xiu, Q. Li, "Material Removal Model and Experimental Verification for Abrasive Jet Precision Finishing with Wheel as Restraint ", Key Engineering Materials, Vols. 304-305, pp. 555-559, 2006
Online since
February 2006
