A Study of Leakage Magnetic Flux Detector Using Hall Sensors Array

It is important to estimate a magnetic field’ intensity distribution for the application of to industrial nondestructive evaluations. A magnetic camera provides the same spatial resolution and a distribution of a quantitative magnetic field with homogeneous lift-off. The method for arraying sensors is important on the magnetic camera because it must obtain a high spatial resolution. This work proposes an equation to evaluate the limitation of spatial resolution on the condition of the decided size of a magnetic sensor package. The possibility of obtaining the high spatial resolution in spite of the above-mentioned limitation would also be verified.
