Paper Title:
Dynamic Characteristic of HSK Tooling System
  Abstract

According to in-depth analysis of the interface between HSK shank and the spindle, the dynamic characteristic of HSK tool system in high speed machining is studied and numerical simulation is carried out with FEM. The HSK tool system deformation, contact stress and the change law of dynamic stiffness were opened out systematically. The relationship between the dynamic stiffness and loading capacity was given. The rotational speed per minute when HSK taper coordination position fails can be named limit maximum rotational speed Nmax of HSK. This provides the foundation for the design of the high speed machine tool.

  Info
Periodical
Key Engineering Materials (Volumes 315-316)
Edited by
Zhejun Yuan, Xipeng Xu, Dunwen Zuo, Julong Yuan and Yingxue Yao
Pages
440-444
DOI
10.4028/www.scientific.net/KEM.315-316.440
Citation
G. C. Wang, S.L. Wang, H. J. Pei, W. G. Wu, X.J. Hua, "Dynamic Characteristic of HSK Tooling System", Key Engineering Materials, Vols. 315-316, pp. 440-444, 2006
Online since
July 2006
