Paper Title:
Study on the Two-Axle Bending with Elastic Roller Forming Technique of Non-Circular Cross-Section Tubular Parts Based on the Feed Force Control
  Abstract

Two-Axle Bending Technique with Elastic Roller (TABTER) is a kind of advanced manufacturing method for bending tubular parts, specially suiting for the difficult-to-work metal materials with high specific strength, and it can obtain a finer forming accuracy. Now the technique has been applied to bend split-sleeve and missile body cylinder successfully. In existed theories, the forming precision of the parts is controlled by adjusting the feed distance between the two axles. But because of the aging problem of the elastic roller and other uncertain factors, the feed force may be different even using the same feed, thus the forming precision cannot be ensured. To solve this problem, the forming theory by controlling the feed force between the two axles is proposed. Then the NC model of forming the non-circular cross-section tubular parts based on the theory is built. At last, the NC prototype machine is developed and some experiments are carried out on the machine.

  Info
Periodical
Key Engineering Materials (Volumes 315-316)
Edited by
Zhejun Yuan, Xipeng Xu, Dunwen Zuo, Julong Yuan and Yingxue Yao
Pages
748-752
DOI
10.4028/www.scientific.net/KEM.315-316.748
Citation
J. Yan, D. W. Zuo, M. Wang, "Study on the Two-Axle Bending with Elastic Roller Forming Technique of Non-Circular Cross-Section Tubular Parts Based on the Feed Force Control ", Key Engineering Materials, Vols. 315-316, pp. 748-752, 2006
Online since
July 2006
Export
Price
$32.00
