Paper Title:
Experimental Study on the Structural Safety Assessment of the Tilting Bolster Frame
  Abstract

This study has performed the experimental study to assess the structural safety of a bolster frame that is applied to the bogie system of Korean tilting train. In order to achieve this goal, firstly, loading conditions imposed on the bolster frame were investigated. Based on the international standard and dynamic analysis, the loading conditions were derived. In this study, the dynamic load cases that consider the carbody tilting effect were established. The structural safety of the bolster frame was evaluated by static test under these static loads and the fatigue strength was assessed using Goodman diagram. From the assessment, the bolster frame has satisfied the structural safety. In addition, fatigue test was carried out up to 1x107cycles under tilting load condition established in this study. The inspection of fatigue crack using NDT method was conducted at 6x106 and 1x107 cycles.

  Info
Periodical
Key Engineering Materials (Volumes 321-323)
Edited by
Seung-Seok Lee, Joon Hyun Lee, Ik Keun Park, Sung-Jin Song, Man Yong Choi
Pages
603-606
DOI
10.4028/www.scientific.net/KEM.321-323.603
Citation
J. S. Kim, N. P. Kim, S. H. Han, "Experimental Study on the Structural Safety Assessment of the Tilting Bolster Frame", Key Engineering Materials, Vols. 321-323, pp. 603-606, 2006
Online since
October 2006
