Paper Title:
An Accurate Digital Grinding Method on Inner Surface of Thin-Walled Rotary Part
  Abstract

The physics performance of thin-walled rotary parts made of hard brittle material on high-speed aerocraft cannot meet the technical requirements after semi-finished processing, in order to compensate the physics performance, the wall thickness should be properly grinded based on the inner surface reference in the finish machining. A processing method consisted of measuring, calculating and grinding functions is investigated. The data of complex surface is obtained with trigger measuring technology, and the reconstructed profile is calculated with cubic polynomial approaching algorithm, which has fast and stable merits in suit with efficient machining. The grinding G program is generated according to the concrete construction of machining tool. This method has been verified by experiments.

  Info
Periodical
Edited by
Dongming Guo, Tsunemoto Kuriyagawa, Jun Wang and Jun’ichi Tamaki
Pages
137-144
DOI
10.4028/www.scientific.net/KEM.329.137
Citation
Z.W. Ren, Y. Q. Wang, Z. Y. Jia, X.J. Sheng, "An Accurate Digital Grinding Method on Inner Surface of Thin-Walled Rotary Part", Key Engineering Materials, Vol. 329, pp. 137-144, 2007
Online since
January 2007
Export
Price
$32.00
