Paper Title:
Static Characteristic Analysis of a 3-DOF Micropositioning Table for Grinding
  Abstract

In order to improve the machining accuracy of the precision surface grinding machine, a 3-DOF micropositioning table is used as an auxiliary table to form the dual infeed system with nanometer level positioning accuracy. This paper mainly deals with the static characteristics of the micropositioning table. The direct and inverse kinematic models are obtained under different orientation descriptions, and the inherent relationship between different orientation descriptions is investigated. By use of Eular angle description, the reachable orientation space of the micro-positioning table is obtained. The theoretical static stiffness on the top surface of the table is also given, and the experimental tests are carried out to verify the established models.

  Info
Periodical
Edited by
Shen Dong and Yingxue Yao
Pages
177-182
DOI
10.4028/www.scientific.net/KEM.339.177
Citation
Y. L. Tian, D. W. Zhang, B. Yan, "Static Characteristic Analysis of a 3-DOF Micropositioning Table for Grinding", Key Engineering Materials, Vol. 339, pp. 177-182, 2007
Online since
May 2007
Export
Price
$32.00
