Paper Title:
Experimental Research of On-Line Fabrication of Tool-Electrode Base on Electrochemical Micromachining
  Abstract

A new method for on-line fabrication of micro tool-electrodes is presented in this paper. The method is base on the machining mechanism of electrochemical micromachining. By exchanging the polarities of the tool-electrodes and workpiece repeatedly, micro tool-electrode appropriate for electrochemical micromachining can be obtained through mutual machining. Because the processes are carried out on-line, the position error and clamp error caused by twice-clamp of tool-electrodes can be avoided, and the machining precision can be improved greatly. This method will be very important to electrochemical generating micromachining. Experiments are carried out, and a tool-electrode with the pinpoint of 20μm can be machined stably.

  Info
Periodical
Edited by
Shen Dong and Yingxue Yao
Pages
302-306
DOI
10.4028/www.scientific.net/KEM.339.302
Citation
Z. N. Guo, F.Z. Zeng, G.H. Han, Z. G. Huang, "Experimental Research of On-Line Fabrication of Tool-Electrode Base on Electrochemical Micromachining", Key Engineering Materials, Vol. 339, pp. 302-306, 2007
Online since
May 2007
Export
Price
$32.00
Share
