Paper Title:
A Novel Architecture for Compiled-Type Software CNC System
  Abstract

PC-based software computer numerical control (CNC) system is the ideal for open CNC system, but there are some problems about the current open CNC system, such as the limitation of interpolation cycle, demanding on high-speed and high precision machining and the limitation of operation system (OS). So advances a novel PC-based architecture for compiled-type software CNC system, in the architecture, the general Windows is adopted as CNC platform and adopts two huge memories acting as data buffer to solve real time problem. And then analyzes the structure and basic principle of compiling system. The hardware has been developed based on this architecture and applied in the CNC system.

  Info
Periodical
Edited by
Shen Dong and Yingxue Yao
Pages
442-446
DOI
10.4028/www.scientific.net/KEM.339.442
Citation
Y. X. Yao, S. Z. Yu, "A Novel Architecture for Compiled-Type Software CNC System", Key Engineering Materials, Vol. 339, pp. 442-446, 2007
Online since
May 2007
