Paper Title:
A Study on the Micro Property Testing of Micro Embossing Patterned Metallic Thin Foil
  Abstract

In this paper, Experimental results on the measurement of mechanical properties of fine patterns in the MEMS structure are described. The mechanical properties of embossing patterns on metallic thin foil is measured using the nano indentation system, that is developed by Korea Institute of Industrial Technology(KITECH). These micro embossing patterns are fabricated using CIP(Cold Isostatic Press) process on micro metallic thin foils(Al-1100) that are made by rolling process. These embossing patterned metallic thin foils(Al-1100) are used in the reflecting plate of BLU(Back Light Unit) and electrical/mechanical MEMS components. If these mechanical properties of fine patterns are utilized in a design procedure, the optimal design can be achieved in aspects of reliability as well as economy.

  Info
Periodical
Key Engineering Materials (Volumes 345-346)
Edited by
S.W. Nam, Y.W. Chang, S.B. Lee and N.J. Kim
Pages
335-338
DOI
10.4028/www.scientific.net/KEM.345-346.335
Citation
H. J. Lee, N. K. Lee, H. W. Lee, "A Study on the Micro Property Testing of Micro Embossing Patterned Metallic Thin Foil", Key Engineering Materials, Vols. 345-346, pp. 335-338, 2007
Online since
August 2007
