Paper Title:
FE Analysis and Position Accuracy Estimation of Machining System for Lens of Mobile Devices
  Abstract

In order to obtain competitiveness in the field of industrial manufacturing, a reduction in the development period for the batch machining of products is required. It is essential to analyze the stress distribution and deformations of machining system which is used for manufacturing the aspheric lens using FEM software ANSYS. Finite element simulations have been performed in order to study the influence of machining system which was developed in this study on structures. It is very important to understand the structural behavior of machining system. This research investigated the static analysis and dynamic analysis of machining system for aspheric lens to predict the damage due to loading.

  Info
Periodical
Key Engineering Materials (Volumes 364-366)
Edited by
Guo Fan JIN, Wing Bun LEE, Chi Fai CHEUNG and Suet TO
Pages
1197-1202
DOI
10.4028/www.scientific.net/KEM.364-366.1197
Citation
S. Y. Baek, E. S. Lee, J. H. Lee, M. J. Shin, "FE Analysis and Position Accuracy Estimation of Machining System for Lens of Mobile Devices", Key Engineering Materials, Vols. 364-366, pp. 1197-1202, 2008
Online since
December 2007
