Paper Title:
A Study on Tool Deflection Trend Using Real Captured Images in Micro Endmilling Process
  Abstract

Recently, ultra-precision micro patterns and shapes have been widely used in optical field. Various methods which are based on semi-conductor fabrication methods are nowadays used in fabrication of micro shapes and patterns, but micro endmilling technology has lately attracted considerable attention because of various available materials, flexibility of process and high-productivity. For the precision micro endmilling process, analysis of micro cutting error is mandatory. In general, tool deflection is a major factor which causes cutting error and limits realization of the high-precision cutting process. Specially, in micro endmilling process, micro tool deflection generates very serious problems compared to macro tool deflection. In this paper, it is performed to observe the real tool deflection shapes in micro endmilling process, so the trend of micro tool deflection was analyzed using real captured images in this study. To get the real images of micro tool deflection, micro slot cutting processes were executed under various cutting conditions using micro endmill and the real images of tool deflection were obtained during cutting process by high-speed camera. Finally, the extent of tool deflection was calculated by the deflection angle according to cutting conditions and two trends (the point of first tool contact and the cutting stage) of micro tool deflection were analyzed.

  Info
Periodical
Key Engineering Materials (Volumes 364-366)
Edited by
Guo Fan JIN, Wing Bun LEE, Chi Fai CHEUNG and Suet TO
Pages
662-667
DOI
10.4028/www.scientific.net/KEM.364-366.662
Citation
G. H. Kim, G. S. Yoon, Y. M. Heo, S. H. Jang, T. I. Seo, M. W. Cho, "A Study on Tool Deflection Trend Using Real Captured Images in Micro Endmilling Process", Key Engineering Materials, Vols. 364-366, pp. 662-667, 2008
