Paper Title:
Fabrication of Cylindrical Tungsten Microelectrode by Electrical Machining
  Abstract

Developed with micro technology, the microelectrode is the key manufacture technique. The micro electrical machining, mainly including micro electrical discharge machining (EDM) and electrochemical machining (ECM), is one of the important technologies of microelectrode fabrication. Firstly, the microelectrode was fabricated with a counter block of EDM while the cylindrical tungsten electrode fed along radius and its axis. Then the fabrication technology of ECM was also introduced. The pulses power supply and the non-passivation electrolyte were used. The cylindrical tungsten electrode also can be served as the probe of the scanning probe microscopy, which fabricated by ECM. Through comparisons, the surface roughness, machining efficiency, and machining capability of the microelectrode fabricated by ECM are better than those of the microelectrode fabricated by EDM, but the shape and the microhardness are worse than those of the microelectrode fabricated by EDM. Both of them can fabricate the cylindrical tungsten microelectrodes with several micrometers diameter.

  Info
Periodical
Key Engineering Materials (Volumes 375-376)
Edited by
Yingxue Yao, Xipeng Xu and Dunwen Zuo
Pages
298-302
DOI
10.4028/www.scientific.net/KEM.375-376.298
Citation
B. G. Zhu, Z. L. Wang, B. X. Jia, "Fabrication of Cylindrical Tungsten Microelectrode by Electrical Machining", Key Engineering Materials, Vols. 375-376, pp. 298-302, 2008
Online since
March 2008
