Paper Title:
Measurement and Analysis of Radial Error Motion of a Miniature Ultra-High-Speed Spindle
  Abstract

The optical measuring device developed in this study is based on laser autocollimation and can measure the radial error motions of a miniature ultra-high-speed spindle having a maximum rotational speed of 200 krpm. The maximum response frequency of this optical measuring device is over 500 kHz, while the frequency of the radial error motion at 200 krpm is 3.33 kHz for 1 undulation per revolution (upr), and 333 kHz for 100 upr. In addition, the optical measuring device is capable of a highly detailed analysis of the radial error motion of a miniature ultra-high-speed spindle since it has a high signal-to-noise ratio due to little susceptibility to electrical noises.

  Info
Periodical
Key Engineering Materials (Volumes 381-382)
Edited by
Wei Gao, Yasuhiro Takaya, Yongsheng Gao and Michael Krystek
Pages
73-76
DOI
10.4028/www.scientific.net/KEM.381-382.73
Citation
K. Fujimaki, K. Mitsui, "Measurement and Analysis of Radial Error Motion of a Miniature Ultra-High-Speed Spindle", Key Engineering Materials, Vols. 381-382, pp. 73-76, 2008
Online since
June 2008
