Research of Ultrahigh Speed Grinding Spindle System Based on Squeeze Film Damping Technology |
| Journal |
Key Engineering Materials (Volumes 389 - 390) |
| Volume |
Advances in Abrasive Technology XI |
| Edited by |
Tsunemoto Kuriyagawa, Libo Zhou, Jiwang Yan and Nobuhito Yoshihara |
| Pages |
67-71 |
| DOI |
10.4028/www.scientific.net/KEM.389-390.67 |
| Online since |
September, 2008 |
| Authors |
Tian Biao Yu, Ya Dong Gong, Hu Li, Jian Yu Yang, Wan Shan Wang |
| Keywords |
Grinding Wheel Spindle, Squeeze Film Damper, Squeeze Film Stiffness, Ultra-High Speed Grinding |
| Abstract |
Ultrahigh speed grinding is a kind of high efficient metal cutting method. In order to improve
ability of ultrahigh greed grinding wheel spindle to resist vibration and grinding quality, an
ultrahigh speed grinding spindle system with a squeeze film damper (SFD) was designed based on
the theory of squeeze film damping technology. Pressure distribution and squeeze film stiffness
characteristic of SFD was study by the method of simulation. Based on theory study an ultrahigh
speed spindle system with a SFD was designed and experiments were done. The study results show
that application of SFD technology can effectively restrain vibration which is caused by the
imbalance quality when the grinding wheel spindle turning at ultrahigh speed. And the speed of the
grinding spindle is higher and the effect of attenuation of SFD to grinding spindle is better.
Research works provides a new technology for the design of the ultrahigh speed grinding spindle
system. |
