Paper Title:
Research of Hydraulic Jack Leakage Diagnosis Emulation Base on Wavelet /AMEsim
  Abstract

Researches the leak malfunction of hydraulic cylinder, which is the center typical part of hydraulic pressure system. Use wavelet transform in detect the signal oddity aspect; the wavelet transform can examine the mutation points such as saltation signal, pulse signal and the signal biggest value etc. Tries to resolve leakiness breakdown the problem of the diagnosis in the new thinking. Examining accurately a time difference of pressure ascension points can judge if there is leak or not and severe degree of leak.It makes use of wavelet excellent zoom ability in space time and the graphical development environment of AMEsim , constructs the system mold, imitates to really analyze with dynamic state function, according to imitate a true result , the accuracy and the possibility of wavelet analysis method in diagnosing the leak malfunction of hydraulic cylinder can be got.

  Info
Periodical
Key Engineering Materials (Volumes 392-394)
Edited by
Guanglin Wang, Huifeng Wang and Jun Liu
Pages
103-108
DOI
10.4028/www.scientific.net/KEM.392-394.103
Citation
B.D. Jing, S. Lu, L.Z. Yang, H. Wu, "Research of Hydraulic Jack Leakage Diagnosis Emulation Base on Wavelet /AMEsim", Key Engineering Materials, Vols. 392-394, pp. 103-108, 2009
Online since
October 2008
