Paper Title:
Research on Dynamic Performance of Milling System for Parallel Indexing Cam Contour Milling
  Abstract

Cutting force model for flat end milling and dynamic model of cam milling system were established based on the analysis of machining system for parallel indexing cam contour milling. Solution for dynamic performance of this kind of milling system has been introduced. A system, consisting of NC milling machine SK1632K3, tooling and workpiece, has been taken as example to analyze how cutting speed, feeding, or processing redundancy influence the dynamic performance of machining system. Furthermore, milling error of cam contour has been evaluated corresponding to different machining parameters. Simulation and analysis results are very close to practical manufacturing situation.

  Info
Periodical
Key Engineering Materials (Volumes 392-394)
Edited by
Guanglin Wang, Huifeng Wang and Jun Liu
Pages
156-160
DOI
10.4028/www.scientific.net/KEM.392-394.156
Citation
P. Q. Guo, S. R. Wang, J. P. Shi, N. Fan, W. Wang, "Research on Dynamic Performance of Milling System for Parallel Indexing Cam Contour Milling", Key Engineering Materials, Vols. 392-394, pp. 156-160, 2009
