Paper Title:
Imageware and Pro/E Based Reverse Engineering Techniques for Drawbar in Heavy-Duty Railway Freight Cars
  Abstract

As a new for heavy-railway vehicle connecting device, drawbar can eliminate connective gap and improve dynamic performance of the train obviously as it is well interchangeable, simple structure, easy manufacture, convenient maintenance, mature technology, high reliability, and widely applied abroad. Through the research on reverse engineering of foreign drawbar, authors present data collecting method based on the coordinates measuring machine (CMM) and data preprocessing by Imageware software, which including noise points removal, data alignment, simplification, sorting and benchmark transformation. Converting points cloud data by Pro/E independent geometric module, 3D models based on features and constraints were reconstructed, which support the redesign of parts and their manufacturing analysis. The outcome of the paper provides effective ways in terms of drawbar techniques digesting and absorption, and also supports innovative design of new products.

  Info
Periodical
Key Engineering Materials (Volumes 392-394)
Edited by
Guanglin Wang, Huifeng Wang and Jun Liu
Pages
320-324
DOI
10.4028/www.scientific.net/KEM.392-394.320
Citation
B. H. Lu, H.P. Zheng, "Imageware and Pro/E Based Reverse Engineering Techniques for Drawbar in Heavy-Duty Railway Freight Cars", Key Engineering Materials, Vols. 392-394, pp. 320-324, 2009
Online since
October 2008
