Paper Title:
Parametric Design on 3D Complex Groove of Turning Inserts Using Pro/Engineer
  Abstract

One main method of chip breaking is to use the grooves which can make chips be broken. 3D complex grooves meet the requirements of controllable chip breaking. It is too complicated to design 3D complex grooves using AutoCAD in short periods because each section of them is intricacy. Thus the author established the parametric model of the groove based on the advanced functions of Pro/Engineer, in which parameters can be obtained, transferred and modified through setting up parameter relations and compiling control programs. The combination of representative elements constituting the solid model of 3D complex grooves can be achieved by just inputting parameters, which can be directly transformed into 2D drawing accordingly; the heavy work of drawing complex surfaces using AutoCAD can be avoided; and the curvature of each normal profile of grooves are gotten. All such work lays a foundation for the groove design and optimization.

  Info
Periodical
Key Engineering Materials (Volumes 392-394)
Edited by
Guanglin Wang, Huifeng Wang and Jun Liu
Pages
724-728
DOI
10.4028/www.scientific.net/KEM.392-394.724
Citation
X.M. Feng, G. Y. Tan, "Parametric Design on 3D Complex Groove of Turning Inserts Using Pro/Engineer", Key Engineering Materials, Vols. 392-394, pp. 724-728, 2009
Online since
October 2008
