Paper Title:
Template-Based Process Planning System for Special Bearing
  Abstract

This paper reports the work of web-based auto-design machining process of special bearing. A template-based process planning method is proposed for auto generating machining process of special bearing, including turning process and grinding process of inner ring or outer ring. Process templates are customized to generate process, procedures size and size tolerance are calculated according to procedure size database. A web-based process planning system is developed based on the proposed method. The use of the system is illustrated with an example.

  Info
Periodical
Key Engineering Materials (Volumes 407-408)
Edited by
Fan Rui, Qiao Lihong, Chen Huawei, Ochi Akio, Usuki Hiroshi and Sekiya Katsuhiko
Pages
243-247
DOI
10.4028/www.scientific.net/KEM.407-408.243
Citation
S. F. Jiang, C. F. Lu, C. D. Lu, "Template-Based Process Planning System for Special Bearing", Key Engineering Materials, Vols. 407-408, pp. 243-247, 2009
Online since
February 2009
Export
Price
$32.00
