Paper Title:
Ultra Precision Diamond Shaping of an Elliptical Micro-Lens Array
  Abstract

Micro lens array is widely used in photonics and telecommunication products, including back-light module of flat panel display devices and white-light LED illumination. The ultra precision diamond shaping method together with tool servo technique was studied and developed in this research to generate elliptical micro lens array. Each elliptical micro lens has radii in X and Y direction of 1.0 mm and 1.5 mm respectively. A high filling-factor (100 %) elliptical micro lens array with form accuracy better than 0.15μm and surface roughness around 5nm Ra was successfully fabricated.

  Info
Periodical
Key Engineering Materials (Volumes 407-408)
Edited by
Fan Rui, Qiao Lihong, Chen Huawei, Ochi Akio, Usuki Hiroshi and Sekiya Katsuhiko
Pages
380-383
DOI
10.4028/www.scientific.net/KEM.407-408.380
Citation
C. L. Chao, C. C. Chen, W. C. Chou, "Ultra Precision Diamond Shaping of an Elliptical Micro-Lens Array", Key Engineering Materials, Vols. 407-408, pp. 380-383, 2009
Online since
February 2009
