Paper Title:
Effect of Ultrasonic Vibration of Tool on Electrical Discharge Machining of Sintered NdFeB Magnet
  Abstract

Sintered NdFeB magnet is widely used in many areas because of its excellent magnet. This paper studies the effect of ultrasonic vibration of tool on electrical discharge machining of it. Experiments were carried out on self-made equipment and material removal rate(MRR) against pulse-on time, MRR versus peak current and machined surface results with and without ultrasonic employment were analyzed. Results show that MRR of the ultrasonic assisted electro-discharge machining would be up to five times higher than MRR of the conventional EDM for small pulse durations and low discharge currents. The machined surface of US/EDM is finer than EDM because of less arcing and short circuit pulses. There are less cracks on the surface.

  Info
Periodical
Key Engineering Materials (Volumes 407-408)
Edited by
Fan Rui, Qiao Lihong, Chen Huawei, Ochi Akio, Usuki Hiroshi and Sekiya Katsuhiko
Pages
628-631
DOI
10.4028/www.scientific.net/KEM.407-408.628
Citation
L. Li, Z. W. Niu, G. M. Yuan, "Effect of Ultrasonic Vibration of Tool on Electrical Discharge Machining of Sintered NdFeB Magnet", Key Engineering Materials, Vols. 407-408, pp. 628-631, 2009
Online since
February 2009
