Paper Title:
Process Planning and Program Generation for STEP-Compliant NC Manufacture of Complex Surface Components
  Abstract

A framework for process planning and NC programming based on STEP and STEP-NC data model is proposed in this paper. The STEP standard and its data structure for CAD models, especially the NURBS based representation of complex surfaces is analyzed. Then the general strategy for process planning using the STEP-NC data structure is presented, and the calculation of cutter contact points and cutter location data for producing complex surfaces based on the geometrical information is addressed. Finally a prototype system is developed for demonstration of the proposed STEP-compliant NC programming approach for complex surface components.

  Info
Periodical
Key Engineering Materials (Volumes 419-420)
Edited by
Daizhong Su, Qingbin Zhang and Shifan Zhu
Pages
441-444
DOI
10.4028/www.scientific.net/KEM.419-420.441
Citation
R. L. Liu, Y. F. Xu, Y. R. Wang, C. R. Zhang, "Process Planning and Program Generation for STEP-Compliant NC Manufacture of Complex Surface Components", Key Engineering Materials, Vols. 419-420, pp. 441-444, 2010
Online since
October 2009
