Paper Title:
Research on Terahertz Filters Employing the Effect of Frustrated Total Internal Reflection
  Abstract

The optical filter under development employing frustrated total internal reflection is a micromechanical device containing two silicon rectangular prisms. There is flat silicon plane among hypotenuse edges of the prisms. The silicon plane is a Fabry-Perot resonator, with clearances h1 among the plate and prism edges being its mirrors. Theoretical resolution of the optical filter would be R ≈ 1,5∙103 if h1 = 50 µm and R ≈ 3∙105 if h1 = 100 µm with the thickness of the silicon plane being h = 65 µm; wavelength λ = 100 µm; free spectral region Δλ/λ ≈ 0,3…0,4, transmission in the maximum of spectral characteristics 0,6 (provided input and output silicon prism legs bloom).

  Info
Periodical
Edited by
Yuri Chugui, Yongsheng Gao, Kuang-Chao Fan, Roald Taymanov and Ksenia Sapozhnikova
Pages
281-285
DOI
10.4028/www.scientific.net/KEM.437.281
Citation
A. S. Syrneva, V. V. Chesnokov, D. V. Chesnokov, "Research on Terahertz Filters Employing the Effect of Frustrated Total Internal Reflection", Key Engineering Materials, Vol. 437, pp. 281-285, 2010
Online since
May 2010
