Paper Title:
Research and Development of Four Axis Linkage Grinding Simulation System of Ball-Nose End Mill
  Abstract

The four axis linkage grinding simulation system of ball-nose end mill has be developed based on the mathematical model of four axis linkage grinding through establishing ball-nose end mill's parametrical database, constructing ball-nose end mill’s and grinding wheel's solid models in Solidworks, simulating the grinding processes of the rake face and flank face of ball-nose end mill based on Boolean operation, and automatic NC programming of rake face and flank face grinding. The results show the grinding simulation system can be used to manufacture ball end mill.

  Info
Periodical
Edited by
Jun Wang,Philip Mathew, Xiaoping Li, Chuanzhen Huang and Hongtao Zhu
Pages
314-317
DOI
10.4028/www.scientific.net/KEM.443.314
Citation
L. He, X. F. Zhao, H. Y. Shi, J. Wang, "Research and Development of Four Axis Linkage Grinding Simulation System of Ball-Nose End Mill", Key Engineering Materials, Vol. 443, pp. 314-317, 2010
Online since
June 2010
Export
Price
$32.00
