Paper Title:
An Analysis of Non-Uniform Deformation of a Pantograph for Bellows Applications
  Abstract

In this study, an analytical model is developed to analyze non-uniform deformation of a pantograph. The analytical model is verified by comparing predicted deformations with experimentally measured deformations of a pantograph. The effects of total displacement and gaps on non-uniformity are numerically simulated to provide the physical insight into the deformation mechanism of a pantograph. Design guidelines are suggested to minimize non-uniform deformation of a pantograph, and hence also of an associated bellows.

  Info
Periodical
Key Engineering Materials (Volumes 452-453)
Edited by
A. Saimoto and M.H. Aliabadi
Pages
585-588
DOI
10.4028/www.scientific.net/KEM.452-453.585
Citation
J. H. Kim, B. K. Jang, K. S. Kim, J. Y. Kim, B. I. Choi, S. H. Jun, J. H. Kim, "An Analysis of Non-Uniform Deformation of a Pantograph for Bellows Applications", Key Engineering Materials, Vols. 452-453, pp. 585-588, 2011
Online since
November 2010
Export
Price
$32.00
