Paper Title:
Microscope Measurement of Jet-Pan Based on CCD
  Abstract

The jet-pan is a key part of jet-pan servo valve. Required precision of jet-pan should be guaranteed in process. CCD microscope measurement is used to deals with the measurement of jet-pan in the paper. The worepiece is enlarged by the optical microscope, and a series of image processing algorithms is used to process the image. The basic dimensions and geometrical tolerance of jet-pan are measured. And the stability error is less than ±0.5μm.

  Info
Periodical
Edited by
Bo Zhao, Guanglin Wang, Wei Ma, Zhibo Yang and Yanyan Yan
Pages
525-529
DOI
10.4028/www.scientific.net/KEM.455.525
Citation
D. X. Shao, J. Li, Z. S. Lu, G. L. Wang, "Microscope Measurement of Jet-Pan Based on CCD", Key Engineering Materials, Vol. 455, pp. 525-529, 2011
Online since
December 2010
Export
Price
$32.00
Share
