Paper Title:
Analysis on Forming Characteristics of Cup-Shaped Thin-Walled Inner Gear Spinning
  Abstract

Spin-forming is a new near net-shape forming process for cup-shaped thin-walled inner gear (CTIG). The CTIG spinning was investigated by numerical simulation and processing experiments. The results show that the compressive deformation along tangential direction on the internal surface of part leads to a reduction in root circle of spun part; and the local loading and friction work result in the nonuniform radial deformation on the external surface of spun part. For spin-forming of CTIG with a small number of teeth, the diameter reduction is feasible for improving the forming quality of tooth groove, while the nonuniform radial deformation would cause concaves on external surface of part. For spin-forming of CTIG with a large number of teeth, the diameter reduction is not conducive to removing the part from the mandrel.

  Info
Periodical
Edited by
Bo Zhao, Guanglin Wang, Wei Ma, Zhibo Yang and Yanyan Yan
Pages
544-547
DOI
10.4028/www.scientific.net/KEM.455.544
Citation
L.Y. Sun, B. Y. Ye, Q.X. Xia, X. Q. Cheng, "Analysis on Forming Characteristics of Cup-Shaped Thin-Walled Inner Gear Spinning", Key Engineering Materials, Vol. 455, pp. 544-547, 2011
Online since
December 2010
Export
Price
$32.00
