Paper Title:
Finger Milling-Cutter NC Generating Spiral Bevel Gear Tooth Surfaces & its Machining Simulation
  Abstract

Based on the in-depth study the principle of NC generating gear tooth surfaces by application of the disc milling-cutter, finger milling-cutter NC generating spiral bevel gear tooth surfaces is presented in this paper. Through using a 5 shaft 4 linkage machining center, the finger milling-cutter is mounted on the imagination disc milling-cutter, in fact, 2 NC axes are used simultaneously to control the finger milling-cutter motion, imitating a blade motion of disc milling-cutter, and the motion of the blank is not change, to generate the spiral bevel gear tooth surfaces. A spiral bevel pinion is simulation machined by using machining simulation system VERICUT and the feasibility of the machining method is verified.

  Info
Periodical
Edited by
Long Chen, Yongkang Zhang, Aixing Feng, Zhenying Xu, Boquan Li and Han Shen
Pages
501-505
DOI
10.4028/www.scientific.net/KEM.464.501
Citation
G. G. Li, X. Z. Deng, B. Y. Wei, "Finger Milling-Cutter NC Generating Spiral Bevel Gear Tooth Surfaces & its Machining Simulation", Key Engineering Materials, Vol. 464, pp. 501-505, 2011
Online since
January 2011
