Paper Title:
Effect of Elastic Mismatch and Anisotropy on Cracking of Brittle Films on Elastic Substrates
  Abstract

The paper analyzes the depth and spacing of cracks in a tensile strained In0.25Ga0.75As epitaxial layer on a InP substrate using the minimum energy theorem. The elastic anisotropy of both the layer and the substrate is considered. The concept of weight function obtained numerically by means of detailed FEM is employed.

  Info
Periodical
Edited by
Pavel Šandera
Pages
235-238
DOI
10.4028/www.scientific.net/KEM.465.235
Citation
M. Kotoul, T. Vyslouzil, "Effect of Elastic Mismatch and Anisotropy on Cracking of Brittle Films on Elastic Substrates", Key Engineering Materials, Vol. 465, pp. 235-238, 2011
Online since
January 2011
