Paper Title:
The Software Design of Inverter Test System Based on VC and NI Controls
  Abstract

The I/O performance test system of inverter is designed. ADlink PCI board and signal regulating panel are core of hardware platform. The software uses the mixed programs, that is, the graph control of Labview and Microsoft Visual C++. Based on the eight analog inputs, two analog outputs, three digital inputs and four digital outputs provided with specific application, we fulfill the following assignments: the dynamic monitoring of three-phase input current/voltage, DC-bus voltage and actual rotation speed, curve drawing and data storage. The computer could give the enable signal and analog speed of inverter, besides the failures are read and displayed. Finally the harmonic analysis and the balance analysis of three-phase current/voltage are realized.

  Info
Periodical
Key Engineering Materials (Volumes 467-469)
Edited by
Dehuai Zeng
Pages
2002-2006
DOI
10.4028/www.scientific.net/KEM.467-469.2002
Citation
W. L. Cao, B. Chen, Y. Y. He, "The Software Design of Inverter Test System Based on VC and NI Controls", Key Engineering Materials, Vols. 467-469, pp. 2002-2006, 2011
Online since
February 2011
