Paper Title:
Research on Dimensional Variable Groove Cutting Machine of CNC H-Beam Wedge Head
  Abstract

H-beam wedge heads are traditionally cut by manual operation. Considering the complex operation, high labor intensity and poor quality of the manual operation, a dimensional variable groove cutting machine of CNC H-beam wedge head is developed in the research, which concerns mechanical components and numerical systems. The mechanical structure are introduced first, especially gradeless piercing gas line. In the CNC system, based on minimum deviation method, a real-time interpolation algorithm is adopted and successfully applied. The human-computer interface of CNC system is also represented. Some machinable typical work pieces are illustrated also

  Info
Periodical
Edited by
Daizhong Su, Kai Xue and Shifan Zhu
Pages
53-56
DOI
10.4028/www.scientific.net/KEM.486.53
Citation
K. Xue, Y. Q. Li, F. Liu, "Research on Dimensional Variable Groove Cutting Machine of CNC H-Beam Wedge Head", Key Engineering Materials, Vol. 486, pp. 53-56, 2011
Online since
July 2011
