Paper Title:
Measurement and Control Device of Preloaded Ball Screw Drive
  Abstract

The deviation often appears in the feeding device of machine because of the screw spindle geometry torsional moment and the wear. The automatic compensation of the changes was proposed by means of a ball screw pretightening device by using adjustable force measurement and control. The detail design and simulation were conducted for the specific device. A case study was presented for the CNC lathe’s application. Testing results have shown that the device can be easily operated with an acceptable precision for positioning.

  Info
Periodical
Edited by
Daizhong Su, Kai Xue and Shifan Zhu
Pages
73-76
DOI
10.4028/www.scientific.net/KEM.486.73
Citation
X. F. Ma, C. Hao, F. Q. Li, "Measurement and Control Device of Preloaded Ball Screw Drive", Key Engineering Materials, Vol. 486, pp. 73-76, 2011
Online since
July 2011
Export
Price
$32.00
