Paper Title:
Ultra-Precision Fabrication of Small-Size Aspherical Glass Lens Mold
  Abstract

With the rapid development of opto-electronics communications, optics, aerospace and other industries, ultra-precision aspheric glass lenses are widely used in middle/high-grade optical opponent because of its high resolution and imaging quality. To achieve ultra-precision molding pressing of micro-lens, ultra-precision mold must be fabricated firstly. In this paper, some key new technologies were proposed for fabricating ultra-precision mold of small-size aspheric optical lens. A method of finite element simulation was employed to predict mould pressing process of the glass lens for correcting molds and improving the formation efficiency. An ultra-precision inclined-axis grinding and error compensation technology was also used to improve form accuracy of micro lens mold.

  Info
Periodical
Edited by
Feng Zhu, Xipeng Xu and Renke Kang
Pages
29-33
DOI
10.4028/www.scientific.net/KEM.487.29
Citation
F. J. Chen, S. H. Yin, J. W. Yu, K. J. Zhu, Y. Wang, "Ultra-Precision Fabrication of Small-Size Aspherical Glass Lens Mold", Key Engineering Materials, Vol. 487, pp. 29-33, 2011
