Paper Title:
Solutions for Interpreting STEP-NC Based Part Program
  Abstract

STEP-NC is a new CNC data interface proposed to replace ISO 6983, and has been partly formed into the draft international standard (ISO 14649). In this paper, the STEP-NC-based part program is analyzed, and the general methodology and tools for STEP-compliant application development are introduced. Then a framework for STEP-NC interpreter is proposed based on the SDAI method and the implementation solutions are presented. The EXPRESS compiler is used to convert the milling schema into C++ classes, and the information is extracted from the file in aid of data access tools. The said interpreter, which is fundamental to STEP-NC based machining, is also implemented with supporting tools in the ST-Developer environments. It is used to read the STEP-NC file into ROSE working form, and then extract and organize the manufacturing information in an object-oriented way.

  Info
Periodical
Materials Science Forum (Volumes 471-472)
Edited by
Xing Ai, Jianfeng Li and Chuanzhen Huang
Pages
344-347
DOI
10.4028/www.scientific.net/MSF.471-472.344
Citation
R. L. Liu, C. R. Zhang, "Solutions for Interpreting STEP-NC Based Part Program", Materials Science Forum, Vols. 471-472, pp. 344-347, 2004
Online since
December 2004
Export
Price
$32.00
