Paper Title:
Research on Precision Forging Law of Complicated Blade by Using 3D FE Simulation and Physical Modeling
  Abstract

Research on precision forming laws of complicated blade has been a challenging issue on international frontiers of plastic forming areas. The precision forging laws of the blade with a damper platform have been obtained by using 3D FE simulation and physical modeling. The laws involve in the deforming characteristics of the tenon, damper platform, middle blade body, and tip blade body, such as the unevenness of deformation and material flow, the branch-flow of material, material flow characteristic of the blade body and rotation forming characteristic of the damper platform. The research may serve as a guide to the optimization design of relevant process and dies.

  Info
Periodical
Materials Science Forum (Volumes 471-472)
Edited by
Xing Ai, Jianfeng Li and Chuanzhen Huang
Pages
839-843
DOI
10.4028/www.scientific.net/MSF.471-472.839
Citation
M. Zhan, H. Yang, Y. L. Liu, "Research on Precision Forging Law of Complicated Blade by Using 3D FE Simulation and Physical Modeling", Materials Science Forum, Vols. 471-472, pp. 839-843, 2004
Online since
December 2004
