Paper Title:
Applications of LIGA on Micro-Punching Process for Metallic Materials
  Abstract

This study presents an innovative imprinting method to fabricate IC devices by micro-punch process. Normally, imprinting method is used to imprint plastic materials such as photoresist and polymeric materials. In this study, imprinting process is applied to micro-punch metallic materials directly for IC devices. Fabrications of IC devices with high aspect ratio structures ranging from micrometer to sub-micrometer are described. In this study, to keep the production costs as low as possible, a complete micro-punching process is applied to replicate IC devices. A combination of lithography, extra-hard alloy nickel cobalt (Ni/Co) electroplating process (as a metal imprint mold for punch) and chemical mechanic polishing (CMP) process is used to flat the extra-hard alloy micro-punch head. It is worth noticing that the Ni-Co electroplating process with hardness over Hardness of Vicker (Hv) 560 is developed. With such hardness, it can stand the high pressure and abrasivness to confine the accuracy during micro-punching process. With regard to the electroplating process, Ni-Co is deposited and covered on the photoresist template uniformly by electroplating. The Ni/Co mold is served as master for micro-punching process to replicate the pattern onto polyimide (PI) or copper sheets. Finally, the experimental results are measured and characterized.

  Info
Periodical
Materials Science Forum (Volumes 505-507)
Edited by
Wunyuh Jywe, Chieh-Li Chen, Kuang-Chao Fan, R.F. Fung, S.G. Hanson,Wen-Hsiang Hsieh, Chaug-Liang Hsu, You-Min Huang, Yunn-Lin Hwang, Gerd Jäger, Y.R. Jeng, Wenlung Li, Yunn-Shiuan Liao, Chien-Chang Lin, Zong-Ching Lin, Cheng-Kuo Sung and Ching-Huan Tzeng
Pages
55-60
DOI
10.4028/www.scientific.net/MSF.505-507.55
Citation
C.T. Pan, P.J. Cheng, S.C. Shen, M.F. Chen, R.Y. Wang, M. C. Chou, T. C. Wu, "Applications of LIGA on Micro-Punching Process for Metallic Materials", Materials Science Forum, Vols. 505-507, pp. 55-60, 2006
Online since
January 2006
