Paper Title:
Study on Eccentricity and Minimum Geometrical Center Distance of the Eccentric Involute Gears Transmission
  Abstract

The traditional design and analysis method for the eccentric involutes gears transmission has model error. Some important parameters, such as minimum geometrical center distance and eccentricity, are not calculated accurately. The differential equation of eccentric involute gears transmission is established on account of the geometrical relationship of eccentric involute gears transmission. A calculating method of the geometrical center distance and eccentricity are derived. The relationship between the minimum geometrical center distance or maximum transmission ratio and initial meshing angle and eccentricity are analyzed. The minimum geometrical center distance and eccentricity are fitted by polynomial. The analysis and design can be completed fast and accurately by using polynomial fitting formals, so the process of analysis and design are simplified.

  Info
Periodical
Materials Science Forum (Volumes 505-507)
Edited by
Wunyuh Jywe, Chieh-Li Chen, Kuang-Chao Fan, R.F. Fung, S.G. Hanson,Wen-Hsiang Hsieh, Chaug-Liang Hsu, You-Min Huang, Yunn-Lin Hwang, Gerd Jäger, Y.R. Jeng, Wenlung Li, Yunn-Shiuan Liao, Chien-Chang Lin, Zong-Ching Lin, Cheng-Kuo Sung and Ching-Huan Tzeng
Pages
985-990
DOI
10.4028/www.scientific.net/MSF.505-507.985
Citation
J. G. Han, G. C. Wang, "Study on Eccentricity and Minimum Geometrical Center Distance of the Eccentric Involute Gears Transmission", Materials Science Forum, Vols. 505-507, pp. 985-990, 2006
Online since
January 2006
